Lamella clarifiers enhance the traditional sedimentation process by incorporating inclined plates or tubes, providing a larger effective settling area within a compact footprint.



This technology is designed to improve particle settling efficiency and optimize the use of space in sedimentation basins.

Between Several designs, Tikal recommends

1- Chevron Tube Settler

An innovative design, a choreography that optimizes settling efficiency.



  • Optimized Tube Configuration: Tubes are strategically arranged to maximize settling surface area.
  • Tube Inclination for Enhanced Performance: Tubes set at 45-60 degrees optimize gravitational forces.
  • Hydraulic Efficiency: Hydraulic loading rates range from 6 to 13 m³/m².hr.
  • Solids Removal Efficiency: Removal rates range from 70% to 90%.
  • Particle Size Handling: Effective for particles as small as 20 micrometers.
  • Footprint Efficiency: Compact design saves 20-50% space.
  • Energy Consumption: Operates under gravity, minimizing energy use.
  • Biosolids Concentration: Achieves 2-5% solid concentrations in dewatered sludge.

2- Parallel Plate Settlers

  • Parallel plate settlers compose a symphony of closely spaced.
  • Plates are set at a precise inclination angle, typically ranging between 45 to 60 degrees, ensuring optimal particle settling and water drainage.
                 Surface Area Optimization:
  • The surface area for settling is maximized through the careful arrangement of closely spaced plates.
  • Our PPS units provide up to 2-3 times the settling surface area compared to traditional sedimentation tanks.
  • Achieve hydraulic loading rates range from 1 to 5 m³/m².hr, showcasing exceptional efficiency.

3-Hexagonal Tube Settlers

Hexagonal Configuration for Superior Efficiency
  • Tikal’s Hexagonal Tube Settlers feature a unique arrangement of tubes, forming a hexagonal pattern that maximizes the settling surface area.
  • Settling surface area: Achieve a 30% increase in compared to traditional square or circular tube settler designs.

                Hydraulic loading rates

  • Low to Moderate Loading Rates: in the range of 1 to 3 m³/m².hr, For applications where a high degree of solids removal is required, such as in drinking water treatment plants, hydraulic loading rates

           Moderate to High Loading Rates

                 rates in the range of 3 to 5 m³/m².hr or higher may be                        employed.

Tikal Advantages

  1. Expanded Settling Stage
  2. Efficiency Crescendo
  3. Spatial Ballet
  4. Turbulence Waltz
  5. Maintenance Nocturne

Products Tikal Provide

Tube Settler

lamella Supports

Washing System
